Upgraded Furibee X140
By Snorkl FPV on Jul 10, 2018
I used a 20x20 stack plate to mount VTX on top and RX on the bottom. There are 6 servo connector pins protruding from the FC where the stock VTX used to plug into. Since there is a lot of space in this frame I did not bother desoldering or cutting them but used longer nylon standoffs instead.
The drone uses F.Port on UART 1.
Gearbest used to sell the frame seperately but seems to have stopped doing so.
Part List
Show stores (5)Guides & Reviews
AirbladeUAV has done it again and this time they've brought long range to the 5" class! Based on the popular Transformer Mini, the new Transformer 5" Ultralight adopts a lot of the same design philosophies with larger props and more payload capacity. It can fly upwards of 20 minutes on a 4 cell Li-Ion battery pack and in ideal conditions it's got a range of over 4 to 5 miles. In this guide I'll walk..
Read more
With the release of the DJI FPV Drone cinematic FPV has become a lot more accessible, but you certainly don't want to crash a $750 drone! The QAV-CINE Freybott is a compact, lightweight cinematic FPV drone that can take a hit and keep going. It's a lot safer to fly indoors and around people. With a naked GoPro or the SMO 4k you can capture some great stabilized footage. In this guide I'll show you..
Read more
I see you've used the SPC maker 20x20 F3 FC and 20A 4in1 ESC.
I am looking at using the same pair (just ordered from Banggood but not yet arrived) for a project of my own (replacing F4 FC and individual ESCs - saves a lot of weight). I am a bit concerned about the wiring of ESC to FC.
Info on Banggood site says power, gnd + the 4x ESC signal lines all come via a (supplied) 6 pin loom between the two. However, found a youtube video of someone who fried the FC doing that. Then looking at some FC pictures, seems to imply the +V connection of the FC is for +5V, but also others that the ESC actually puts VBAT (ie 12V with 3s) on that connection.
That would certainly kill the FC if it was expecting 5V and got 12V.
On the other hand, if the ESC genuinely puts out 5V, not 12V, then VBAT monitoring would not be possible on the FC (because it doesn't see VBAT).
Don't want to make an expensive mistake, so wondering how you wired it?
The FC is specified for 2 - 4S input voltage (so 17V max) and gets power either from the 4in1 ESC via a 6-pin cable from the 4in1 ESC (which I used) or directly from the battery. I do not know what caused the FC on the video to fry but I run this combo on 3 quads on 4S without any problem so far. There is a layout diagram on SPCMaker's website.
https://www.spcmaker.com/spcmaker-vx86-1-ominibus-f3-flight-controller-integrated-with-osd-module-p0058.html
Thanks for that, it is what I hoped to hear. What slightly worried me was (a) the youtube video and (b) I had a feeling I had somewhere seen a drawing marked +5v not VBAT for that pin. Made me wonder if there were two versions of the FC.
I also see you are using an R-XSR as I am also intending, but with F. Port as opposed to SBUS / S. Port. I assume you got the uninverted S. Port from the pad on the R-XSR, as opposed to the S. Port connector pin?
